Layer Cages
Best® layer cage - chicken cage manufacturer since 1996



How to choose chicken layer cage for your poultry farm?
1. Your farm planning
1) below 2000 birds, we advice you choose manual layer cage, drinking system is automated, workers will put food in chicken trough and picked eggs, in future if you want to enlarge your farm to 10,000+ birds, our automatic feeding equipment and automatic egg collection will be installed on the using layer cage directly
2) between 5000 birds to 10,000 birds, beside layer cage, we advice you choose manure removal system, chicken dropping cleaning on time will reduce disease and improve egg production rate, meanwhile it will save much more time and labor cost.
3) Beyond 15,000 birds, some automatic equipment should be installed, you will own two or more chicken house, it is easy to manage, such as automatic egg collection, works once or twice a day.

2. Lifespan of Layer cage
Layer cage ‘s lifespan from 5 years up to 20 years, it depends on material of manufacturer using and climate of your countries, Our economical cage is using in our own farm for 8 years in China now and our quality layer cage is using in our African such as Nigerian customers’ farm for 10 years now.

Tips: when you send us your inquiry, please tell us,
which country are you from?
How many chicken do you start?
Our service department will give you layer cage picture and house drawing after you supply us your land size or your chicken house size.
  • Why choose
  • Project
  • Specification
  • Feature
  • Package
  • Maintaining
Why Layer Cages by Best® is The Best for Chicken rearing and laying Eggs?
 Raw material selection
Carbon content decides the metal wire hardness, our metal wire for cage ordered from China big steel factory, high hardness and high elastic deformation, make the cage mesh no deformation, cage lifespan improves 3 years at least than common factory
 Up to 20 years using
Quality hot deep galvanized cage mesh will ensure your cage that it remains protected from corrosion and rust for 10 years at least
 Cage mesh design
Big sliding door design is easy to pick chicken, The density of bottom cage mesh can prevent feather and anus pecking and prevent layer chicken fatigue syndrome.
 save the land area
saves 50% of the land than Cage-free type breeding. have a  good ventilation and lighting, efficiently prevent disease infection, improve the survival rate and egg collection of chicken.


 After the egg laying grow up to 12 week or 16 weeks, it starts laying egg, then transfer them to layer cage
 Your layer cage layout will be designed as your chicken house, freely supply house design and layerout
 Normally the walking way is between 0.7m to 1m, building pit under cage system, the distance between the wall and cage row is 0.7m


It is A type, according to capacity per set, the specification is as followed

Type A-96 A-120 A-128 A-160 A-200
Item 3 tiers /4 doors 3 tiers /5 doors 4 tiers /4 doors 4 tiers /5 doors 4 tiers /5 doors
Set capacity 96 birds 120 birds 128 birds 160 birds 160 birds
Cell capacity 4 birds 4 birds 4 birds 4 birds 4 birds
Cage size
(L*W*H)
1.9m*1.9m*1.6m 2.0m*1.9m*1.62m 2.0m*2.3m*1.9m 2.0m*2.4m*1.9m 2.0m*3m*1.95m
Cell size
(L*W*H)
47cm*34cm*37cm 39cm*34cm*37cm 49cm*35cm*38cm 39cm*35cm*38cm 40cm*40cm*40cm

Fittings details

Name Description
Water pipe new PVC material,
no deformation,high temperature resistance,not easy to damage.
Nipple drinker warranty>10 years
Stainless steel ball inside nipple drinker
 Feed trough loading capacity>60kg/pc, White PVC material,
adults can walking on it and not easy to be damaged during transport
Galvanized cage mesh One cage basket
Door, top mesh, back mesh, bottom mesh and partition mesh
Steel cage frame warranty>20 years
Iron bar, Galvanization surface treatment,
Fixing accessories Connector of water pipe and feeding trough
Cage clips, cage frame nuts and so on
Water pressure controlling system Including the terminal device and water-split device,supply average water to the pipe
Type A-96 A-120 A-128 A-160 A-200
Item 3 tiers /4 doors 3 tiers /5 doors 4 tiers /4 doors 4 tiers /5 doors 4 tiers /5 doors
Set capacity 96 birds 120 birds 128 birds 160 birds 160 birds
Cell capacity 4 birds 4 birds 4 birds 4 birds 4 birds
Cage size
(L*W*H)
1.9m*1.9m*1.6m 2.0m*1.9m*1.62m 2.0m*2.3m*1.9m 2.0m*2.4m*1.9m 2.0m*3m*1.95m
Cell size
(L*W*H)
47cm*34cm*37cm 39cm*34cm*37cm 49cm*35cm*38cm 39cm*35cm*38cm 40cm*40cm*40cm

Feature
 Strong and durable – high strength welded mesh with solid solder joint;
 Corrosion protection – electro or hot dipped galvanized optional;
 Long service life – more than 10 years lifetime;
 Increased density of bottom fabric – prevent the egg laying chickens feet from malformation or tiredness;
 Unique cage door design – up and down sliding door, or left and right sliding door;
 Easy to assemble and use – no need professional technicians;
 Excellent natural ventilation environment – more fresh air on all tier;
 Land & Space Saving – Centralized management, saving the land resource;
 No chicken manure on eggs – keep the chicken eggs from dirty;
 Eggs won’t be broken or fall out – improving egg production
 Reduce the waste of feed – saving your expenses.



The cage and frame are no package , some fittings are in plastic bags and carton box.
1. Less of full container: below 80 sets, first packed with plastic film then on the pallets
2. Full container: Nude packing

Type 20 ft container 40 ft high container
A-96 130 SETS 280 SETS
A-120 130 SETS 280 SETS
A-160 100 SETS 210 SETS
A-200 80 SETS 160 SETS
1. After finish installation, clean the feeding trough
2. Connect water, to make sure the whole drinking system is well from row beginning to end
3. After 2 years using, move all birds, clean the cage mesh
4. Replace the nipple drinkers if they link water to protect brid feather, medicinal water will make feather fall off
